16bit sequential divider with adjustable decomal point

DIVIDEdividersDIVIDE005Archived Feb 15, 2026

✅Tested & Functional

Authors:MNbiom

Endorsed by:mattbatwings

View

Its an 16bitDefinition: Guide to data storage sizes: **Bit**: The smallest unit of data, representing a 0 or a 1 in binary. Abbreviated as b **Nibble**: One hexadecimal 'digit,' representing either **4 bits** or the 16 ... sequentialDefinition: Includes memory or state. The output is the result of the input AND a memory element. For example, a counter is sequential. When the 'count' input is pressed, the output depends on what is already ... divider with adjustable decimal point. So you can set whether is should calculate 16.0 or 15.1 ... or 1.15 (integer.fraction (amount of bits))

Input

A(16bit), B(16bit), amount of fractional bits(hexDefinition: The Base 16 number system. In minecraft, this term is synonymous with signal strength because there are 16 signal strength values (0-15).), button to start(9rt pulse)

Output

A/B, A%B

Speed

9rt/bit + initial 7rt (151rt for 16.0(best case); 286rt for 1.15(worst case))

Notes

A%B output sometimes outputs 1rt pulse, so you might have to filter it with a torch or a comparator
