WafPortsV2

IOPORTio-portsIOPORT001Archived Feb 15, 2026

✅Tested & Functional

Authors:Waffle [Wueffi]

Endorsed by:Waffle [Wueffi]

View

Isorender of my IO-Ports.

Seven very sleek (4-wide) single busDefinition: A wire or collection of wires which transfer data from one place to another IO-ports with a total volume of 3915 Blocks.

Input

7 8b binary Inputs

Output

7 8b binary Outputs

Speed

3rt Read, 6rt Write

Notes

Control-/Feedback-lines (top to bottom): Data Out, Toggle Write (OFF = Read, ON = Write), Address bitDefinition: Guide to data storage sizes: **Bit**: The smallest unit of data, representing a 0 or a 1 in binary. Abbreviated as b **Nibble**: One hexadecimal 'digit,' representing either **4 bits** or the 16 ... 2, Address bit 1, Address bit 0
