Set-Reset (SR) Latch

LFFlatches-flipflopsLFF007Archived Feb 15, 2026

✅Tested & Functional⭐Recommended

Endorsed by:mattbatwings

View

Becomes "Set" when set is pressed, or becomes "Reset" when reset is pressed.

Notes

If set and reset are pressed simultaneously, it will end in the "Set" state.
