Configurable clock

OTHERSEQother-sequentialOTHERSEQ003Archived Feb 15, 2026

✅Tested & Functional⭐Recommended

Endorsed by:mattbatwings

View

A clock with configurable period and pulse length.

Notes

Increase/decrease the delay going into the side of the first comparator to change the period. Increase/decrease the delay going into the side of the second comparator to change the pulse length.
