8x 8-bit Register File

REGISTERFILEregister-filesREGISTERFILE002Archived Feb 15, 2026

✅Tested & Functional

Authors:mattbatwings

Endorsed by:mattbatwings

View

A collection of 8 registers addressable in binary, with the ability to write to or read from any register. Highlights the ability to stackDefinition: LIFO: A data structure where the last input is outputted first (LIFO, Last in first out). For example, when the numbers 1, 2, 3, 4 are inputted in that order, they are outputted in the reverse ord... registers every 2 blocks.

Input

8b number, 3b register address, Write button, Read button

Output

8b number
