Shift Registers w/ Load (Up & Down versions)

SHIFTshift-registersSHIFT001Archived Feb 15, 2026

✅Tested & Functional⭐Recommended

Authors:mattbatwings

Endorsed by:mattbatwings

View

An upward shift register and downward shift register, both with load.

Input

8b number, Load button, Shift button

Output

8b number
