8bit Square Rooter

SQRTsquarerootersSQRT002Archived Feb 15, 2026

✅Tested & Functional

Authors:SafetyIWisher

Endorsed by:mattbatwings

←→

1 / 3

View

Above view of square-rooter near the remainder.

8-bitDefinition: Guide to data storage sizes: **Bit**: The smallest unit of data, representing a 0 or a 1 in binary. Abbreviated as b **Nibble**: One hexadecimal 'digit,' representing either **4 bits** or the 16 ... sequentialDefinition: Includes memory or state. The output is the result of the input AND a memory element. For example, a counter is sequential. When the 'count' input is pressed, the output depends on what is already ... square root extractor

Input

8-bit Number, Extraction Button

Output

4-bit Square Root, 5-bit Remainder

Speed

Total of 71 rTicks after button press

Notes

Once the button is pressed, it takes 2 tickDefinition: Different units of time used in Minecraft redstone. Normally, the game runs at 20 game ticks per second (this can be changed by lag or using the /tick command). Therefore, a **game tick is general...s to initiate the circuit. The Square Root is saved 4 rTicks after the Remainder, and the circuit is cleared for 1 cycle, 1 rTick after the Root is saved. 1 cycle lasts 13 rTicks, so it takes 8t for init, 4 clock cycles, and 11 ticks to finish saving and clearing. This uses a Non-restoring / trial subtraction Binary Digit-by-Digit Square Root Algorithm.
